The UPS Power Supply High-Frequency Transformer produced by Haoer manufacturer supports a wide frequency range of 20kHz to 500kHz. The output power can be flexibly configured within the range of 15W to 1000W, and it has strong adaptability. Its operating temperature range is -40℃ to +125℃, which is suitable for harsh high and low temperature environments; the storage temperature range is -25℃ to 85℃, and it can be stored for a long time under a relative humidity of 30% to 95%, demonstrating excellent environmental stability.
| 1. Operating frequency | 20 kHz - 500 kHz |
| 2. Output power | 15 to 1000 W |
| 3. Operating temperature | -40°C to +125°C |
| 4. Storage temperature | -25°C to +85°C |
| 5. Storage humidity | 30% - 95% |
Good magnetic shielding performance, compact structure, high power, high efficiency, low magnetic leakage, strong anti-interference ability, etc.
PQ2016/ PQ2020/ PQ2620/PQ2625 /PQ3225 /PG3230 /PQ3535 /PQ4040 /PQ5050
DC-DC converters, LED driving power supplies, inverter power supplies, UPS power supplies
| PART NO. | TERMINAL PINS | Dimensions in mm(inches) | ||||||
| A | B | C±0.5 | D±0.5 | E | E1 | F | ||
| PQ2016 | 14 | 18.5 | 23.2 | 20.3 | 4 | 5 | 3.8 | 23.1 |
| PQ2020 | 14 | 22.3 | 23 | 20.3 | 4 | 5 | 3.8 | 23 |
| PQ2620 | 12 | 20 | 29.3 | 25.4 | 4 | 7.7 | 3.8 | 26.6 |
| PQ2625 | 12 | 28.5 | 29.6 | 25.5 | 4 | 7.62 | 3.8 | 27 |
| PQ3220 | 12 | 23.5 | 34.4 | 30.7 | 4 | 7.62 | 5.08 | 32.4 |
| PQ3230 | 12 | 33.5 | 34.2 | 30.7 | 4 | 7.52 | 5.08 | 32.3 |
| PQ3535 | 12 | 37.5 | 39.1 | 35.6 | 5 | 10.16 | 5.08 | 35 |
| PQ4040 | 12 | 41.5 | 42 | 38 | 5 | 15 | 5 | 40 |
